90mm Brushless Motor with Ce Certification
Product Description
| Model:FXD 90 BLDC 24 300 | General Info | |
| A B C D E | Winding type | Star/Delta |
| Note: A Fuxianda | Hall effect angle | 120 degree electric angle |
| B Motor dia or square size | Shaft runout | 0.025mm |
| C Brushless DC Motor | Radial play | 0.06mm/50g |
| D Rated voltage | End play | 0.08mm/50g |
| E Rated power | Max radial force | 28/N20mm from the flange |
| Max axial force | 10N |
Motor specification
| Model | No.of Phase | Rated Voltage | Rated Speed | Rated Torque | Rated Power | Mass | Body length |
| VDC | rpm | N.m | W | Kg | mm | ||
| FXD90BLDC24300 | 3 | 24 | 2000 | 1.433 | 300 | 2.0 | 110 |
| FXD90BLDC48300 | 3 | 48 | 3000 | 0.955 | 300 | 1.8 | 100 |
| FXD90BLDC310300 | 3 | 310 | 3000 | 0.955 | 300 | 1.6 | 90 |
Applications:
The bldc motor manufactured by us has wide range of application like robots, electronic automatic equipment, medical instrument, advertisementing instrument, lighting& audio equipment, printer, textile machinery, CNC router etc.
Note: If you have some different specifications, we can product Stepper Motor as your special requirements.
Web: http:/// Phone:+86 0519 83666368
http:// Mob: 15295151006
Why choose us? 1. Environmental friendly
2. In time delivery
3. Negotiable and competitive price
4. CE, ROHS, SGS certification
5. In time after-sale service
6. 2-year guarantee period
7. Custom products
We also provide stepper motor, brushless gear motor, brake, driver, customized products etc. You are welcomed to visit our website. http:
